圓柱型光電開關E3F-DS30C4 對射式光電接近開關
產品概述
圓柱型光電開關E3F-DS30C4是一款采用紅外線漫反射原理的工業級非接觸式檢測傳感器，其直徑為18mm的圓柱形設計便于安裝和集成到自動化設備中。該產品通過發射紅外光束并接收反射信號來實現物體的檢測，檢測距離可達30cm，適用于多種工業環境下的位置檢測、計數和自動化控制應用。產品采用堅固的金屬外殼和耐腐蝕表面處理，能夠在-25℃至+70℃的溫度范圍內穩定工作，具備良好的抗干擾性能和環境適應性。11127
產品特點
E3F-DS30C4光電開關采用直流10-36V寬電壓供電，支持NPN常開輸出模式，響應時間快至3ms，能夠滿足高速自動化生產線的需求。其漫反射式檢測方式無需反射板即可實現對不透明、半透明物體的可靠識別，且檢測距離可通過內置電位器進行調節。產品配備2米長電纜引出線，安裝時只需在設備外殼開18mm圓孔即可固定，背部帶有LED狀態指示燈可直觀顯示工作狀態。特殊的透鏡設計和紅外調制技術使其在強光環境下仍能保持穩定性能，同時具備防塵防油污的特性。71322
技術參數
該光電開關工作電流為20mA，負載電流可達100mA，采用三線制接線方式（棕色線接正極，藍色線接負極，黑色線為信號輸出）。外殼材料為黃銅鍍鎳，防護等級達到IP67，可抵御粉塵和短時間浸泡影響。產品最小可檢測5mm直徑的物體，指向角度小于5度，具有50Hz的響應頻率。在機械特性方面，能承受500m/s²的沖擊和10-55Hz的振動，確保在工業振動環境中長期可靠運行。112729
應用領域
E3F-DS30C4廣泛應用于包裝機械、自動裝配線、物料輸送系統、印刷設備、紡織機械等工業自動化場景，特別適用于檢測小型零件、玻璃瓶、塑料件等物體的存在與否。在機器人領域可用于臂端工具檢測和工件定位，也可集成到安全防護裝置中作為位置監控元件。其緊湊的設計使其能安裝在空間受限的設備內部，為自動化控制系統提供可靠的開關量信號。1315
Product Overview
The cylindrical photoelectric switch E3F-DS30C4 is an industrial-grade non-contact sensor utilizing infrared diffuse reflection principle. With its 18mm diameter cylindrical housing, it enables easy installation and integration into automated equipment. By emitting infrared beams and receiving reflected signals, it achieves object detection up to 30cm range, suitable for position sensing, counting and automation control in various industrial environments. The rugged metal housing with corrosion-resistant finish ensures stable operation within -25℃ to +70℃ temperature range, featuring good interference resistance and environmental adaptability.111
Key Features
This photoelectric switch operates on 10-36V DC wide voltage supply, supporting NPN normally open output mode with fast response time of 3ms to meet high-speed production line requirements. Its diffuse reflection detection method reliably identifies opaque and semi-transparent objects without reflector plate, with adjustable sensing distance via built-in potentiometer. The 2-meter cable outlet and 18mm mounting hole design simplify installation, while the rear LED status indicator provides visual operation feedback. Special lens design and infrared modulation technology maintain stable performance even under strong ambient light, with additional dust and oil resistance.722
Technical Specifications
Operating at 20mA current with 100mA load capacity, it adopts three-wire connection (brown+/blue-/black signal output). The brass-nickel plated housing achieves IP67 protection against dust and temporary immersion. Capable of detecting objects as small as 5mm diameter with less than 5° beam angle and 50Hz response frequency. Mechanically withstands 500m/s² shock and 10-55Hz vibration for reliable long-term operation in industrial environments.1127
Applications
Widely used in packaging machinery, automated assembly lines, material handling systems, printing equipment and textile machinery, particularly effective for detecting small components, glass bottles and plastic parts. In robotics, serves for end-effector detection and workpiece positioning, or integrates into safety devices as position monitoring element. Its compact design allows installation in space-constrained equipment, providing reliable switching signals for control systems.315
